GIGABYTE GTX 560 Ti OC

GV-N560OC-1GI

Graphics Processor

GF114

Cores

384

TMUs

ROPs

Memory Size

1024 MB

Memory Type

GDDR5

Bus Width

256 bit

GPU

Graphics Processor

GPU Name: GF114

GPU Variant: GF114-400-A1

Architecture: Fermi 2.0

Foundry: TSMC

Process Size: 40 nm

Transistors: 1,950 million

Density: 5.9M / mm²

Die Size: 332 mm²

Chip Package: BGA-1731

Graphics Card

Release Date: Jan 25th, 2011

Generation: GeForce 500

Predecessor: GeForce 400

Successor: GeForce 600

Production: End-of-life

Bus Interface: PCIe 2.0 x16

Clock Speeds

GPU Clock: ~~823 MHz~~
900 MHz (+9%)

Shader Clock: ~~1645 MHz~~
1800 MHz (+9%)

Memory Clock: 1002 MHz
4 Gbps effective

Memory

Memory Size: 1024 MB

Memory Type: GDDR5

Memory Bus: 256 bit

Bandwidth: 128.3 GB/s

Render Config

Shading Units: 384

TMUs: 64

ROPs: 32

SM Count: 8

L1 Cache: 64 KB (per SM)

L2 Cache: 512 KB

Theoretical Performance

Pixel Rate: ~~13.17 GPixel/s~~
14.40 GPixel/s

Texture Rate: ~~52.67 GTexel/s~~
57.60 GTexel/s

FP32 (float): ~~1,263 GFLOPS~~
1,382 GFLOPS

FP64 (double): ~~105.3 GFLOPS~~
115.2 GFLOPS (1:12)

Board Design

Slot Width: Dual-slot

Length: ~~229 mm~~
241 mm
~~9 inches~~
9.5 inches

TDP: 170 W

Suggested PSU: 450 W

Outputs: 2x DVI
1x mini-HDMI 1.3a

Power Connectors: 2x 6-pin

Board Number: P1040 SKU 50

Graphics Features

DirectX: 12 (11_0)

OpenGL: 4.6

OpenCL: 1.1

Vulkan: N/A

CUDA: 2.1

Shader Model: 5.1

GF114 GPU Notes

PureVideo HD: VP4
VDPAU: Feature Set C

Latest Drivers:
Windows XP / Server 2003 x64:
GeForce Release 368.81

Windows Vista:
GeForce Release 365.19

Windows 7 / 8 / 8.1 / 10:
GeForce Release 391.35

Other retail boards based on this design (29)

Name	GPU Clock	Memory Clock	Other Changes
ASUS GTX 560 Ti DirectCU II	830 MHz	1002 MHz
ASUS GTX 560 Ti DirectCU II TOP	900 MHz	1050 MHz	258 mm/10.2 inches
ASUS GTX 560 Ti DirectCU II TOP 2 GB	900 MHz	1002 MHz	2 GB, 258 mm/10.2 inches
Club 3D GTX 560 Ti	823 MHz	1002 MHz	231 mm/9.1 inches
Club 3D GTX 560 Ti Battlefield 3 Edition 2 GB	823 MHz	1002 MHz	2 GB, 167 mm/6.6 inches
Colorful iGame GTX 560 Ti	900 MHz	1050 MHz	267 mm/10.5 inches
Colorful iGame GTX 560 Ti Kudan	1010 MHz	1125 MHz	305 mm/12 inches, Triple-slot
EVGA GTX 560 Ti 2 GB	823 MHz	1002 MHz	2 GB, 2x DVI 1x HDMI
EVGA GTX 560 Ti Exclusive Overclocked	900 MHz	1002 MHz	2 GB
EVGA GTX 560 Ti FPB	850 MHz	1026 MHz	2x DVI 1x HDMI
EVGA GTX 560 Ti Maximum Graphics Edition Crysis 2	900 MHz	1053 MHz
EVGA GTX 560 Ti Superclocked	900 MHz	1053 MHz	2x DVI 1x HDMI
Gainward GTX 560 Ti GS	900 MHz	1050 MHz	190 mm/7.5 inches, 2x DVI 1x HDMI 1x VGA
Gainward GTX 560 Ti Phantom	835 MHz	1025 MHz	190 mm/7.5 inches, 2x DVI 1x HDMI 1x VGA
Gainward GTX 560 Ti Phantom 2 GB	823 MHz	1002 MHz	2 GB, 190 mm/7.5 inches, 2x DVI 1x HDMI 1x VGA
Galaxy GTX 560 Ti MDT X5	822 MHz	1002 MHz	279 mm/11 inches, 1x DVI 4x HDMI 1x DisplayPort
GIGABYTE GTX 560 Ti OC	900 MHz	1002 MHz	241 mm/9.5 inches
GIGABYTE GTX 560 Ti SOC	1000 MHz	1145 MHz	256 mm/10.1 inches
GIGABYTE GTX 560 Ti SOC Rev. 1.0	950 MHz	1145 MHz	256 mm/10.1 inches
GIGABYTE GTX 560 Ti SOC Rev. 2.0	950 MHz	1145 MHz	255 mm/10 inches
KFA2 GTX 560 Ti EX OC	835 MHz	1000 MHz
KFA2 GTX 560 Ti LTD OC	950 MHz	1100 MHz	230 mm/9.1 inches, 1x DVI 1x HDMI 1x DisplayPort
KFA2 GTX 560 Ti MDT X5	822 MHz	1002 MHz	279 mm/11 inches, 1x DVI 4x HDMI 1x DisplayPort
MSI GTX 560 Ti Golden Edition	900 MHz	1050 MHz	238 mm/9.4 inches
MSI GTX 560 Ti Hawk	950 MHz	1050 MHz	244 mm/9.6 inches
MSI GTX 560 Ti Twin Frozr II OC	880 MHz	1050 MHz	238 mm/9.4 inches
Palit GTX 560 Ti Twin Light Turbo	835 MHz	1025 MHz	188 mm/7.4 inches, 2x DVI 1x HDMI 1x VGA
SPARKLE Calibre GTX 560 Ti DF	950 MHz	1151 MHz
ZOTAC GTX 560 Ti AMP! Edition	950 MHz	1100 MHz
