This processor is not released yet.
Data on this page may change in the future.
Intel Socket 1851
The Intel Core Ultra 7 265 will be a desktop processor with 20 cores, that is expected to launch in October 2024. It is part of the Ultra 7 lineup, using the Arrow Lake architecture with Socket 1851. Core Ultra 7 265 has 33 MB of L3 cache and operates at 2.4 GHz by default, but can boost up to 5.3 GHz, depending on the workload. Intel is building the Core Ultra 7 265 on a 7 nm production process, the transistor count is unknown. The multiplier is locked on Core Ultra 7 265, which limits its overclocking capabilities.
With a TDP of 65 W, the Core Ultra 7 265 consumes typical power levels for a modern PC. Intel's processor supports DDR5 memory with a dual-channel interface. The highest officially supported memory speed is 5600 MT/s, but with overclocking (and the right memory modules) you can go even higher. For communication with other components in the computer, Core Ultra 7 265 uses a PCI-Express Gen 5 connection. This processor features the Arc Xe2 Graphics 64EU integrated graphics solution.
Hardware virtualization is available on the Core Ultra 7 265, which greatly improves virtual machine performance. Additionally, IOMMU virtualization (PCI passthrough) is supported, so that guest virtual machines may directly use host hardware. Programs using Advanced Vector Extensions (AVX) will run on this processor, boosting performance for calculation-heavy applications. Besides AVX, Intel is including the newer AVX2 standard, too, but not AVX-512.
Physical
Socket: |
Intel Socket 1851
|
Foundry: |
Intel |
Process Size: |
7 nm |
Package: |
FC-LGA18V |
tJMax: |
105°C |
Processor
Market: |
Desktop |
Production Status: |
unreleased |
Release Date: |
Oct 2024 |
Part#: |
unknown |
Performance
Frequency: |
2.4 GHz |
P-Core Turbo: | 5.1 GHz |
Turbo Clock: |
up to 5.3 GHz |
E-Core Frequency: |
1800 MHz
up to 4.6 GHz
|
Base Clock: |
100 MHz |
Multiplier: |
24.0x |
Multiplier Unlocked: |
No |
TDP: |
65 W |
PL1: | 65 W |
PL2: | 121 W |
Architecture
Codename: |
Arrow Lake-S |
Generation: |
Ultra 7
(Arrow Lake) |
Memory Support: |
DDR5
|
Rated Speed: |
5600 MT/s
|
Memory Bus: |
Dual-channel
|
ECC Memory: |
No
|
PCI-Express: |
Gen 5, 16 Lanes (CPU only) |
Chipset: |
Z890
|
Core Config
# of Cores: |
20 |
# of Threads: |
20 |
Hybrid Cores: |
P-Cores: 8
E-Cores: 12
|
SMP # CPUs: |
1 |
Integrated Graphics: |
Arc Xe2 Graphics 64EU
|
Cache
Cache L1: |
112 KB (per core) |
Cache L2: |
3 MB (per core) |
Cache L3: |
33 MB (shared) |
E-Core L1: |
96 KB (per core) |
E-Core L2: |
4 MB (per module) |
Features
- MMX
- SSE
- SSE2
- SSE3
- SSSE3
- SSE4.2
- AVX
- AVX2
- FMA3
- SHA
- EIST
- Intel 64
- XD bit
- VT-x
- VT-d
- AES-NI
- TSX
- TXT
- CLMUL
- F16C
- BMI1
- BMI2
- ABM
- ADX
- RdRand
- VNNI
- vPro
- DLBoost 3.0
- TBT 2.0
- TBT 3.0
|
Notes
Intel Arc Xe2 Graphics Dynamic Frequency: 2000 MHz
"Lion Cove" P-Cores
"Skymont" E-Cores |
