NVIDIA Tesla V100 PCIe 32 GB
- Graphics Processor
- GV100
- Cores
- 5120
- TMUs
- 320
- ROPs
- 128
- Memory Size
- 32 GB
- Memory Type
- HBM2
- Bus Width
- 4096 bit
GPU
I/O
Top
Bottom
The Tesla V100 PCIe 32 GB was a professional graphics card by NVIDIA, launched on March 27th, 2018. Built on the 12 nm process, and based on the GV100 graphics processor, the card supports DirectX 12. The GV100 graphics processor is a large chip with a die area of 815 mm² and 21,100 million transistors. It features 5120 shading units, 320 texture mapping units, and 128 ROPs. Also included are 640 tensor cores which help improve the speed of machine learning applications. NVIDIA has paired 32 GB HBM2 memory with the Tesla V100 PCIe 32 GB, which are connected using a 4096-bit memory interface. The GPU is operating at a frequency of 1230 MHz, which can be boosted up to 1380 MHz, memory is running at 876 MHz.
Being a dual-slot card, the NVIDIA Tesla V100 PCIe 32 GB draws power from 2x 8-pin power connectors, with power draw rated at 250 W maximum. This device has no display connectivity, as it is not designed to have monitors connected to it. Tesla V100 PCIe 32 GB is connected to the rest of the system using a PCI-Express 3.0 x16 interface.
Being a dual-slot card, the NVIDIA Tesla V100 PCIe 32 GB draws power from 2x 8-pin power connectors, with power draw rated at 250 W maximum. This device has no display connectivity, as it is not designed to have monitors connected to it. Tesla V100 PCIe 32 GB is connected to the rest of the system using a PCI-Express 3.0 x16 interface.
Graphics Processor
Graphics Card
- Release Date
- Mar 27th, 2018
- Generation
-
Tesla Volta
(Vxx)
- Predecessor
- Tesla Pascal
- Successor
- Tesla Turing
- Production
- End-of-life
- Bus Interface
- PCIe 3.0 x16
Relative Performance
Based on TPU review data: "Performance Summary" at 1920x1080, 4K for 2080 Ti and faster.
Performance estimated based on architecture, shader count and clocks.
Clock Speeds
- Base Clock
- 1230 MHz
- Boost Clock
- 1380 MHz
- Memory Clock
-
876 MHz
1752 Mbps effective
Memory
- Memory Size
- 32 GB
- Memory Type
- HBM2
- Memory Bus
- 4096 bit
- Bandwidth
- 897.0 GB/s
Render Config
- Shading Units
- 5120
- TMUs
- 320
- ROPs
- 128
- SM Count
- 80
- Tensor Cores
- 640
- L1 Cache
- 128 KB (per SM)
- L2 Cache
- 6 MB
Theoretical Performance
- Pixel Rate
- 176.6 GPixel/s
- Texture Rate
- 441.6 GTexel/s
- FP16 (half)
- 28.26 TFLOPS (2:1)
- FP32 (float)
- 14.13 TFLOPS
- FP64 (double)
- 7.066 TFLOPS (1:2)
Board Design
- Slot Width
- Dual-slot
- TDP
- 250 W
- Suggested PSU
- 600 W
- Outputs
- No outputs
- Power Connectors
- 2x 8-pin
- Board Number
- PG500 SKU 202
Graphics Features
- DirectX
- 12 (12_1)
- OpenGL
- 4.6
- OpenCL
- 3.0
- Vulkan
- 1.3
- CUDA
- 7.0
- Shader Model
- 6.8
GV100 GPU Notes
| Tensor Cores: 1st Gen NVENC: 6th Gen NVDEC: 3rd Gen PureVideo HD: VP9 VDPAU: Feature Set I Latest Drivers: Windows 7 / 8 / 8.1 (x64): GeForce Release 474.89 Quadro Release R440 U4 (441.66) Data Center Release 427.11 Windows 10 / 11 (x64): GeForce Release: Latest Quadro Release: Latest Data Center Release: Latest |
