GIGABYTE formally launched its flagship socket TR4 motherboard for AMD Ryzen Threadripper processors, the X399 Designare EX. Positioned slightly above the company's current (and only) offering for this platform, the Aorus X399 Gaming 7, the new Designare EX is based on the same PCB, and a nearly-identical feature-set, except for cosmetic changes, such as its silver-metallic color-scheme dominating the VRM and chipset heatsinks, the M.2 SSD heatspreaders, the I/O shroud and integrated shield, and a back-plate covering most of the reverse side.

Built in the ATX form-factor, the X399 Designare EX draws power from a combination of 24-pin ATX, 8-pin EPS, and 4-pin ATX, conditioning it for the CPU using an 8-phase VRM with "server-grade" chokes, and a VRM heatsink that offloads its heat onto a second heatsink via a heat-pipe. Expansion slots include five PCI-Express 3.0 x16, all of which are wired to the CPU. Storage connectivity includes three 32 Gb/s M.2 slots, and eight SATA 6 Gb/s ports, from which four are directly wired to the CPU.

Aqua Computer rolled out the cuplex kryos NEXT TR4, a variant of their cuplex kryos NEXT flagship CPU water block with support for AMD socket TR4, designed for Ryzen Threadripper HEDT processors. Available in all the variants the cuplex kryos NEXT normally comes in, we have options with a copper, nickel-plated copper, and even silver cold plate variants with POM acetal, acrylic, and metal tops. The blocks feature a dense copper micro-fin lattice with 200 μm spacing between fins, standard G 1/4 threading. These new blocks come with factory-fitted socket TR4 retention modules, and include a tube of Thermal Grizzly Kryonaut thermal compound. Available now, the exposed-copper cold plate variant is priced at 59.90€, and the nickel-plated copper variant at 64.90€ with other variants priced as can be seen on the Aqua Computer web shop. Aqua Computer also mentioned that given the lack of sales of the X399 platform, they are not looking into making a new design to match the larger CPU IHS at this time.

PC enthusiast Der8auer, with access to a Ryzen Threadripper processor, took it completely apart for science. It won't be the first time that a Threadripper HEDT processor was de-lidded (its integrated heatspreader removed), revealing that it has four "Zeppelin" 8-core dies, making it practically identical to AMD's 32-core Epyc processors; however, it's the first time that someone completely removed the dies from the package.

Ryzen Threadripper processors are built by completely disabling two out of four "Zeppelin" dies on an Epyc multi-chip module (MCM). Two diagonally opposite dies are disabled. The disabled dies can't be reenabled, at least not on an X399 chipset motherboard, as the Threadripper HEDT platform lacks DRAM, PCIe, and possibly even power wiring for the disabled dies.

It looks like the Aorus X399 Gaming 7 won't be the only socket TR4 motherboard GIGABYTE has in store for those looking to build Ryzen Threadripper high-end desktops. The first picture of its flagship motherboard for this platform, the X399 Designare EX surfaced thanks to VideoCardz. This board is based on the same exact PCB as the Aorus X399 Gaming 7, including its black PCB color uncharacteristic of the Designare moniker in recent times.

All that's changed is that GIGABYTE swapped out the black colored heatsinks over the chipset and VRM for silver colored ones, and the I/O shroud running the length of the motherboard now comes in silver, and now includes a detachable integrated I/O shield; as well as the M.2 SSD heatsinks. Aorus branding around the board has been swapped for Designare branding. The rest of the board appears to be identical overall. Something still tells us that GIGABYTE could ask a small premium for this board over the Aorus X399 Gaming 7, for its exclusivity and better suitability for white-themed builds.

In a Forbes interview conducted by Anthony Leather, AMD officials Senior Vice President and General Manager Jim Anderson, Corporate Vice President of Worldwide Marketing John Taylor, Sarah Youngbauer of AMD's communications team, and James Prior, AMD's Senior Product Manager, have shed some light on the development process for AMD's equivalent of a flash hit - their HEDT, HCC Threadripper chips. Threadripper, which leverages AMD's Zen architecture used in their Ryzen and EPYC processors, makes use of an MCM design with up to 16 cores and 32 threads, with AMD's svelte Zen, 8-core base units linked through the company's high speed interconnect Infinity Fabric.

This has allowed the company to scale designs from four core processors with Ryzen 3, all the way towards the current cream of the crop Threadripper 1950X. It's an extremely scalable design, which brings with it improved yields and some pretty significant cost savings for AMD due to smaller dies. This, in turn, means the company is able to more agressively price their Ryzen and Threadripper processors compared to the competition, at least when it comes to high core and thread counts for the same price bracket - and the success of that business decision is showing.For our forum lurkers, this article is marked as an editorial.

With the release of AMD's newest flagship CPU, the X399 Threadripper, Phanteks is excited to introduce the Glacier Series C399a. The full CPU waterblock from Phanteks are designed to work seamlessly with AMD's new X399 Threadripper which allows serious overclocking and extreme performance.

Made from premium materials according to the finest standards of craftsmanship from Phanteks, the C399a water block delivers extreme cooling and improve stability under high overclocks for the enthusiasts. The C399a is custom designed for the AMD TR4 socket VITON sealing from the Automotive and Aerospace Industries ensure the best reliability and longevity.

Processor sales numbers of leading German retailer Mindfactory.de show AMD Ryzen processors to be outselling Intel processors for the first time in over a decade. German and EU DIY PC buyers seem to have developed a taste for AMD Ryzen processors, which is reflecting in Mindfactory's sales figures. Since March 2017, when AMD launched its Ryzen 7 series, AMD processor sales have seen a steady growth from 28% (vs. 72% of Intel), to a stunning 56% by the end of August 2017. Mindfactory's sales is a test case of AMD's growth in the DIY processor market, which forced Intel to rush in its Core X family, and its 8th generation Core processor family, which could be out in Q3-2017.

Ryzen 5 1600 appears to be the most popular AMD choice among Mindfactory's customers, as the 6-core/12-thread processor strikes a price-performance sweet-spot at 198€. The chip is outselling the similarly-priced Core i5-7500 by two times, and the i5-7600K by three times. The 8-core/16-thread Ryzen 7 1700 is the second most popular AMD Ryzen part, priced at 288€. From the Intel camp, the Core i7-7700K still commands the single biggest chunk of Mindfactory's CPU sales. As expected, the Ryzen 7 1700X outsells the 1800X by five times. Also, the Ryzen Threadripper 1950X is outselling the Core i9-7900X by over three times. Find more interesting data in the beautifully drawn graphs by Redditor "Type-21."

G.Skill today announced quad-channel kits of its AMD Ryzen-friendly Flare X series, targeted at Ryzen Threadripper HEDT builds. The new 4-module kits come in speeds of DDR4-2133, DDR4-2400, and DDR4-3200; in module densities of 8 GB and 16 GB, making up 32 GB and 64 GB quad-channel kits, respectively; and in color-based variants of black and red. The top-dog DDR4-3200 variant runs at its advertised speeds with timings of 14-14-14-34, and a module voltage of 1.35V. The modules are backed by lifetime warranties; and are typically priced double those of G.Skill's 2-module (dual-channel) Flare X series kits.

At its pre-launch media conference call for the Ryzen Threadripper 1900X, AMD mentioned that the chip has been carved out from the common 4-die EPYC MCM using a "4-0-4-0 diagonal configuration," which led to some confusion as to which cores/dies AMD disabled to carve out the $549 8-core HEDT processor. The company shed some light on this matter, responding to questions from TechPowerUp.

It turns out, that the Threadripper 1900X features an entire CCX (quad-core CPU complex) disabled per active die on the multi-chip module, so the CCX that's enabled has 8 MB of L3 cache; and access to the die's entire uncore resources, such as the dual-channel memory controller, PCIe root complex, etc. With two such active "Zeppelin" dies, the Threadripper 1900X ends up with 8 cores, 16 MB of L3 cache, a quad-channel memory interface, and 64 PCIe lanes.

In a response to AMD's current uptake in the consumer, HEDT and server markets with its vertical slice of the Zen architecture, Intel has started rebranding their products and image, changing product names and placement in a bid to increase the "freshness" factor of its offerings. E5 and E7 Xeons are gone, with the introduction of a metallic naming scheme: Bronze, Silver, Gold and Platinum are now Intel's Xeon products, and Xeon-W takes the spot as Intel's workstation-oriented product stack. They do this by being - essentially - a conversion of Intel's Core i9 X299 family of processors towards the professional market with inclusion of professional-geared features. And as is usual with Intel, a new chipset - C422 - is needed in order for these to properly function.

The new Xeon-W product family will still make use of the LGA 2066 socket, bringing with them ECC and vPro support. The Xeon-W CPU family will feature 4 to 18 cores, support up to 512GB of ECC RDIMM/LRDIMM memory, support dual 512-bit FMAs, and peak clocks of 4 GHz base and 4.5 GHz Turbo. All the parts will support 48 PCIe 3.0 lanes from the processor,and CPUs in the Xeon-W stack are rated at 140W TDP: with exception of the quad cores, which come in at at 120W. Xeon-W processors only support Turbo Boost 2.0, instead of their Core i9 counterparts' Turbo 3.0.

When AMD Ryzen Threadripper HEDT platform launched earlier this year, a shortcoming was its lack of NVMe RAID support. While you could build soft-RAID arrays using NVMe drives, you couldn't boot from them. AMD is addressing this, by adding support for NVMe RAID through a software update, scheduled for 25th September. This software update is in the form of both a driver update (including a lightweight F6-install driver), and a motherboard BIOS update, letting AMD X399 chipset motherboards boot from RAID 0, RAID 1, and RAID 10 arrays made up of up to ten NVMe drives. AMD confirmed that it has no plans to bring NVMe RAID support for the X370 or B350 platforms.

AMD today released the Ryzen Threadripper 1900X eight-core HEDT (high-end desktop) processor. This product is targeted at pro-sumers who could use the quad-channel memory bandwidth and added I/O which the Threadripper HEDT platform brings to the table, but can make do with 8 cores/16 threads, which is why the chip is priced just $50 higher than the 8-core/16-thread Ryzen 7 1800X, at USD $549. The Threadripper 1900X comes with higher clock speeds than the 1800X, with 3.80 GHz nominal clock-speed (compared to 3.60 GHz of the 1800X), 4.00 GHz boost, and XFR adding another 200 MHz to the boost clock, if your cooling is good enough.

The Ryzen Threadripper 1900X gives you the full quad-channel DDR4-3200 memory interface, with support for up to 2 TB memory, and ECC support. There's even unofficial RDIMM support. The chip also offers the full 64-lane PCI-Express interface, with the same PCI-Express device configurations as the higher 1920X and 1950X parts. AMD created the 1900X by disabling two cores per CCX in each of the active 8-core dies on the Threadripper MCM. The chip also only features 16 MB of L3 cache, that's 4 MB per active CCX. Its TDP continues to be rated at 180W. AMD put out its internal testing performance numbers for the 1900X.AMD's performance slides follow.

AMD's third Ryzen Threadripper series HEDT processor SKU, the Threadripper 1900X, started selling in India, ahead of its 31st August scheduled availability. Listed on the country's leading online PC hardware store PrimeABGB, the Threadripper 1900X is priced at INR 45,699. While this price roughly converts to USD $715, which is way above the $549 MSRP announced by AMD, it's important to note that in India the retailer margins and taxes on PC hardware tend to be very high. The same retailer, considered by PC enthusiasts in India as having some of the lowest prices, lists the Threadripper 1920X at INR 65,488 ($1,024), and the Threadripper 1950X at INR 82,008 ($1,283).

The PrimeABGB listing also indicates that the 8-core/16-thread Threadripper 1900X features 16 MB of L3 cache, as opposed to 32 MB on the 1920X and 1950X. This could mean that AMD is configuring the two "Summit Ridge" dies on the 1900X in a 2+2+2+2 CCX configuration, with 4 MB of L3 cache per CCX, just like on the Ryzen 5 1400. The chip still features a quad-channel DDR4 memory interface, and 64-lane PCIe. It is priced between the $390 6-core/12-thread Core i7-7800X and $590 i7-7820X.

Alphacool has been growing their product portfolio immensely as of late, and now, the company is teasing the Eisblock Flatboy, the company's specifically-designed waterblock for AMD's Ryzen Threadripper CPUs. Threadripper CPUs have one of the biggest surface areas ever encountered in a consumer processor; because of that, not all cooling solutions are appropriate to cool the up-to 16 cores and 32 threads monsters, with a higher surface area than normal being needed.

Still in the prototype phase, the Eisblock Flatboy integrates a reverse, silent flow pump system, like the company has already introduced on their Eiswolf product. The prototype as is seems to obstruct clearance for the rightmost DIMM slot to the left of the CPU socket, which shouldn't pose a problem for some people, but would be an extremely sore point for prospective buyers should that design decision overflow towards the final version.

G.SKILL International Enterprise Co., Ltd., the world's leading manufacturer of extreme performance memory and gaming peripherals, announces all-new DDR4 specifications and expanding the Flare X series, designed for AMD processors and platforms. Compatible with the new Ryzen Threadripper processors and AMD X399 chipset motherboards, these new DDR4 specifications are designed to achieve high frequency at DDR4-3600 MHz 32GB (8GBx4), as well as a massive total capacity at DDR4-2933 MHz 128GB (16GBx8). Included in the mix of new quad-channel DDR4 memory kits are DDR4-3200 MHz CL14 32GB (8GBx4) and DDR4-3466 MHz CL16 32GB (8GBx4).

With improved overclocking performance on the latest AMD Ryzen Threadripper processors on the X399 chipset, G.SKILL is announcing the DDR4-3600 MHz CL16-18-18-38 with 32GB (8GBx4) total capacity running in quad-channel mode, under the Flare X series. Tested for maximum stability, this kit's frequency speed marks the fastest memory kit ever released thus far for an AMD platform.

AMD revealed that the pair of 8-core "Summit Ridge" dies that make up the Ryzen Threadripper multi-chip module are heavily binned. AMD hand-selects the top-5% highest performing "Summit Ridge" dies for Ryzen Threadripper manufacturing, which makes these chips of a higher grade than even what AMD sets aside for Ryzen 7-series socket AM4 chips.

AMD requires the highest grade "Summit Ridge" dies to use in Threadripper chips, to keep electrical leakage to the minimum, so the chips can run as cool as possible, with the least power-draw. Choosing the best dies could also ensure that Threadripper chips have the highest overclocking-headroom taking into account other electrical and thermal constraints. A 7-series chip such as the 1800X could still achieve higher clocks than a Threadripper chip, in that sense.

AMD built its Ryzen Threadripper HEDT (high-end desktop) processor as a multi-chip module (MCM) of two 8-core "Summit Ridge" dies, each with its own dual-channel memory controller, and PCI-Express interface. This is unlike the competing Core "Skylake-X" from Intel, which is a monolithic 18-core die with a quad-channel DDR4 interface and 44-lane PCIe on one die. AMD has devised some innovative methods of overcoming the latency issues inherent to an MCM arrangement like the Ryzen Threadripper, by tapping into its nUMA technology innovation.

To the hardware, four 8 GB DDR4 memory modules populating the four memory channels of a Ryzen Threadripper chip is seen as 16 GB controlled by each of the two "Summit Ridge" dies. To the software, it is a seamless block of 32 GB. Blindly interleaving the four 8 GB memory modules for four times the bandwidth of a single module isn't as straightforward as it is on the Core X, and is fraught with latency issues. A thread being processed by a core on die-A, having half of its memory allocation on memory controlled by a different die, is hit with latency. AMD is overcoming this by treating memory on a Ryzen Threadripper machine like a 2-socket machine, in which each socket has its own memory.

Update: Corrected socket compatibility. This is a specially-designed cooler by Arctic for AMD's HEDT platform, As such, it offers limited compatibility with CPUs of lower die sizes, which means it's only compatible with TR4, AM4, LLGA2011(v3) and LGA2066 sockets.

Arctic announced the Freezer 33 TR, a tower-type CPU air cooler, designed for AMD Ryzen Threadripper processors, with out of the box support for AMD socket TR4/SP3r2. The cooler comes in two variants based on color - black with red accents, and black with silver accents. The cooler features a conventional tower-type design, in which four 6 mm-thick copper heat-pipes, which make direct contact with the CPU at the base, pass through an aluminium fin-stack, which is ventilated by an included fan.

Compared to other Freezer 33 variants, the TR variant features an elongated base, for higher coverage of the Threadripper integrated heatspreader (IHS). The aluminium fins and heat-pipes feature matte-black nickel-plating. The included fan takes in 4-pin (PWM) input, spinning between 200 to 1,800 RPM. The cooler can cope with thermal loads of up to 320W, which makes it good for CPU TDP rating up to 200W, according to Arctic. Besides socket TR4, the cooler also supports AMD's AM4 socket, while Intel support stands at their LGA2011(v3), LGA2066. Available now, and backed by a generous 10-year warranty, the Freezer 33 TR is priced at 47.99€.

Noctua is stocking up inventories of its AMD Ryzen Threadripper-compatible NH-U14S-TR4-SP3 tower-type CPU cooler. A variant of the NH-U14S (pictured below), the cooler will be available from 12th August in the United States, through Noctua's eBay store. Other retailers will have stocks by the end of August. Noctua believes the NH-U14S features sufficient muscle to cope with the 180W TDP Threadripper processors, some of the lower variants come with 140W TDP. The TR4-SP3 variant comes with a slightly enlarged base, for better coverage of the large integrated heatspreaders of the Threadripper chips. The other Threadripper-compatible coolers in Noctua's lineup are the NH-U12S-TR4-SP3, and NH-U9-TR4-SP3.

Thermaltake today announced that five of its Water 3.0 Riing series all-in-one, closed-loop, liquid CPU cooler models support AMD Ryzen Threadripper processors in the new TR4 package. Among the supporting models are the Water 3.0 Riing RGB 360, Water 3.0 Riing RGB 240, Water 3.0 Riing RGB 120, Water 3.0 Riing RGB Extreme, and Water 3.0 Riing RGB Ultimate. The five coolers include brackets for socket TR4, although the company didn't mention if the circular blocks of the Water 3.0 Riing RGB series provides 100% coverage of the processors' integrated heatspreader.

Redditor "callingthewolf" has posted what is an awe-inspiring result for AMD's Ryzen Threadripper 1950X (that's an interesting username for sure; let's hope that's the only similarity to the boy who cried wolf.) The 16-core, 32-thread processor stands as the likely taker for the HEDT performance crown (at least until Intel's 14-core plus HEDT CPUs make their debut on the X299 platform.) With that many cores, highly thread-aware applications naturally look to see tremendous increases in performance from any frequency increase. In this case, the 1950X's base 3.4 GHz were upped to a whopping 4.0 GHz (@ 1.25 V core) and 4.1 GHz (at 1.4 V core; personally, I'd stick with the 4.0 GHz and call it a day.)

The feat was achieved under a Thermaltake Water 3.0 liquid cooler, on a non-specified ASRock motherboard with all DIMM channels populated with 8 x 8 GB 3066 MHz DIMMs. At 4.0 GHz, the Threadripper 1950X achieves a 3337 points score on Cinebench R15. And at 4.1GHz, the big chip that can (we can't really call it small now can we?) manages to score 58391 points in Geekbench 3. While those scores are certainly impressive, I would just like to point out the fact that this is a 16-core CPU that overclocks as well as (and in some cases, even better than) AMD's 8-core Ryzen 7 CPUs. The frequency potential of this Threadripper part is in the same ballpark of AMD's 8-core dies, which speaks to either an architecture limit or a manufacturing one at around 4 GHz. The Threadripper 1950X is, by all measurements, an impressively "glued together" piece of silicon.

An unnanounced AMD HEDT Ryzen Threadripper processor has cropped up on some of the most well known motherboard vendors' support lists. Following AMD's product stacking for the Ryzen line of processors, the Threadripper 1920 comes with the same 12 cores and 24 threads as the 1920X, although it runs at lower frequencies (3.2 GHz base, 3.8 GHz Boost on the 1920, against 3.5 GHz and 4.0 GHz on the 1920X). The lower frequency threshold means the 1920 also comes with a lower, 140 W TDP rating (the 1920X has a higher value at 180 W).

These news come courtesy of CPU support lists for the ASUS ROG Zenith Extreme, ASRock X399 Professional Gaming/X399 Taichi as well as GIGABYTE X399-Gaming 7. Expect the new Threadripper to become the sweet spot for the 12-core, 24-thread CPUs of our time, since its performance and pricing will situate it below the 1920X's $799, but above the already announced 8-core Threadripper 1900X, which will come in at $549. Remember that all AMD Zen-based processors come unlocked out of the box for your frequency-increase-through-overclocking pleasure, so it should be relatively simple to extract as much performance from the 1920 as the 1920X can deliver.

Cooler Master has announced support for AMD Ryzen Threadripper and Socket TR4 for its AIO liquid CPU coolers through the usage of a mounting kit (RL-TR4B-MLLS-R1). The list of compatible coolers includes the MasterLiquid 240 and 120, MasterLiquid 240L RGB, MasterLiquid 120L RGB, Lite 240 and Lite 120.

AMD's latest HEDT CPUs offers up to 16 cores and 32 threads which reaches up to 180 watt TDP with the flagship 1950X. Cooler master says AMD's Threadripper CPUs will require top notch cooling, and that Cooler Master's dual chamber cooling presents itself as a perfect option made possible through "the unique cooling process which isolates the heated coolant from the cooled to maximize the results of the cooling of the processor."

LinusTechTips has received an Alienware Area 51, the boutique system which Alienware has developed through its exclusive partnership with AMD for the 16-core, 32-thread Threadripper CPUs.

The system was tested using a proprietary Dell/Alienware motherboard, as well as 32 GB (4x 8 GB) of 2666 MHz DDR4 RAM. Graphics were handled by a Founders Edition GTX 1080 Ti, and storage was etched on a SanDisk A400 256 GB NVME drive (Up to 2050/700 MB/s Sequential Read/Write). The nature of the benchmarked systems, with their myriad of hardware parts, means that the benchmarks are not 100% representative of CPU performance deltas between the tested processors; however, they do put out some interesting numbers. The other HEDT system to be tested was an Intel-based X299 system with a stock Intel Core i9-7900X (10 cores, 20 threads) on an ASUS Prime X299 Deluxe, 4x 8 GB of 3200 MHz DDR4 memory, the same GTX 1080 Ti Founders Edition, and a 512 GB Samsung 950 Pro NVME SSD.

AMD's connectivity-rich Ryzen Threadripper HEDT platform may have an Achilles's heel after all, with reports emerging that it lacks support for booting from NVMe RAID. You can still have bootable NVMe RAID volumes using NVMe RAID HBAs installed as PCI-Express add-on cards. Threadripper processors feature 64-lane PCI-Express gen 3.0 root complexes, which allow you to run at least two graphics cards at full x16 bandwidth, and drop in other bandwidth-hungry devices such as multiple PCI-Express NVMe SSDs. Unfortunately for those planning on striping multiple NVMe SSDs in RAID; the platform lacks NVMe RAID booting support. You should still be able to build soft-RAID arrays striping multiple NVMe SSDs, just not boot from them. Pro-sumers will still be able to dump their heavy data-sets onto such soft-arrays. This limitation is probably due to PCI-Express lanes emerging from different dies on the Threadripper MCM, which could present problems to the system BIOS to boot from.

Ryzen Threadripper is a multi-chip module (MCM) of two 8-core "Summit Ridge" dies. Each 14 nm "Summit Ridge" die features 32 PCI-Express lanes. On a socket AM4 machine, 4 of those 32 lanes are used as chipset-bus, leaving 28 for the rest of the machine. 16 of those head to up to two PEG (PCI-Express Graphics) ports (either one x16 or two x8 slots); and the remaining 12 lanes are spread among M.2 slots, and other onboard devices. On a Threadripper MCM, one of the two "Summit Ridge" dies has chipset-bus access; 16 lanes from each die head to PEG (a total of four PEG ports, either as two x16 or four x8 slots); while the remaining are general purpose; driving high-bandwidth devices such as USB 3.1 controllers, 10 GbE interfaces, and several M.2 and U.2 ports.
