ASUS TUF Gaming Z590-Plus WiFi Review
BIOS Overview »VRM Overview
Specifications
| VRM Specifications | |
|---|---|
| Power Design: | Vcore: Parallel 7-phase SOC: Parallel 1-phase |
| Doublers: | N/A |
| CPU PWM: | Digi+ VRM ASP1900B (X + Y = 8) |
| Power Stages: | Vcore: ON Semiconductor NCP302150 (50 A) SOC: ON Semiconductor NCP302150 (50 A) |
The ASUS TUF Gaming Z590-Plus WiFi features an 8-phase VRM configuration using a parallel—or "Teamed"—power-stage design. Two ON Semiconductor NCP302150 power stages run in parallel for each phase, which gives ASUS double the power-handling capability without using any doublers.
ASUS is using a Digi+ VRM ASP1900B PWM controller to drive the ASUS TUF Gaming Z590-Plus WiFi.
The ASUS TUF Gaming Z590-Plus WiFi uses ON Semiconductor NCP302150 power stages for all phases. These power stages each support a maximum of 50 A of continuous current.
The ASUS TUF Gaming Z590-Plus WiFi has a maximum output of 800 A, with 700 A dedicated to Vcore.
