Power Consumption

Cooling modern video cards is becoming more and more difficult, especially when users are asking for quiet cooling solutions. That's why the engineers are now paying much more attention to power consumption of new video card designs.


In order to characterize a video card's power consumption, the whole system's mains power draw was measured. This means that these numbers include CPU, Memory, HDD, Video card and PSU inefficiency.

The three result values are as following:

• Idle: Windows sitting at the desktop (1024x768 32-bit) all windows closed, drivers installed.
• Average: 3DMark03 Nature at 1280x1024, 6xAA, 16xAF. This results in the highest power consumption. Average of all readings (two per second) while the test was rendering (no title screen).
• Peak: 3DMark03 Nature at 1280x1024, 6xAA, 16xAF. This results in the highest power consumption. Highest single reading

The idle power consumption of the PCS 4850 seems to be slightly down compared to the reference design. Whether this is because of the different cooler or modified power management is unknown. Under load the card draws slightly more same power than the reference design - because of the increased core clock.
