According to the latest TrendForce statistics, revenue of the top ten global IC design houses reached US$39.56 billion in 2Q22, growing 32% YoY. Growth was primarily driven by demand for data centers, networking, IoT, and high-end product portfolios. AMD achieved synergy through mergers and acquisitions. In addition to climbing to third place, the company also posted the highest annual revenue growth rate in 2Q22 at 70%.

Qualcomm continues in the No. 1 position worldwide, exhibiting growth in the mobile phone, RF front-end, automotive, and IoT sectors. Sales of mid/low-end mobile phone APs were weak but demand for high-end mobile phone APs was relatively stable. Company revenue reached US$9.38 billion, or 45% growth YoY. NVIDIA benefitted from expanded application of GPUs in data centers to expand this product category's revenue share past the 50% mark to 53.5%, making up for the 13% YoY slump in its game application business, bringing total revenue to US$7.09 billion, though annual growth rate slowed to 21%. AMD reorganized its business after the addition of Xilinx and Pensando. The company's embedded division revenue increased by 2,228% YoY. In addition, its data center department also made a considerable contribution. AMD posted revenue of US$6.55 billion, achieving 70% growth YoY, highest amongst the top ten. Broadcom's sales performance in semiconductor solutions remained solid and demand for cloud services, data centers, and networking is quite strong. The company's purchase order backlog is still increasing with 2Q22 revenue reaching US$6.49 billion, an annual growth rate of 31%.

Intel Corporation today announced a first-of-its-kind Semiconductor Co-Investment Program (SCIP) that introduces a new funding model to the capital-intensive semiconductor industry. As part of its program, Intel has signed a definitive agreement with the infrastructure affiliate of Brookfield Asset Management, one of the largest global alternative asset managers, which will provide Intel with a new, expanded pool of capital for manufacturing build-outs.

SCIP is a key element of Intel's Smart Capital approach, which aims to provide innovative ways to fund growth while creating further financial flexibility to accelerate the company's IDM 2.0 strategy. Intel's agreement with Brookfield follows the two companies' memorandum of understanding announced in February 2022. Under the terms of the agreement, the companies will jointly invest up to $30 billion in Intel's previously announced manufacturing expansion at its Ocotillo campus in Chandler, Arizona, with Intel funding 51% and Brookfield funding 49% of the total project cost. Intel will retain majority ownership and operating control of the two new leading-edge chip factories in Chandler, which will support long-term demand for Intel's products and provide capacity for Intel Foundry Services (IFS) customers. The transaction with Brookfield is expected to close by the end of 2022, subject to customary closing conditions.

Samsung Electronics today broke ground for a new semiconductor research and development complex in Giheung, Korea, aiming to extend its leadership in state-of-the-art semiconductor technology. Samsung Electronics plans to invest about KRW 20 trillion by 2028 for the complex in an area covering about 109,000 square meters within its Giheung campus. The new facility will lead advanced research on next-generation devices and processes for memory and system semiconductors, as well as development of innovative new technologies based on a long-term roadmap.

Today's groundbreaking ceremony was attended by Samsung Electronics Vice Chairman Jay Y. Lee, President and CEO Kye Hyun Kyung, President of the Memory Business Jung-Bae Lee, President of the Foundry Business Siyoung Choi and President of the S.LSI Business Yong-In Park, along with more than 100 employees.

-AvicenaTech Corp., the leader in microLED-based chip-to-chip interconnects, today announced that the company has secured $25M in Series A funding from Samsung Catalyst Fund, Cerberus Capital Management, Clear Ventures, and Micron Ventures to drive the development of products based on Avicena's breakthrough photonic I/O solution. "We believe that Avicena technology can be transformational in unlocking compute-to-memory chip-to-chip high-speed interconnects. Such technology can be central to supporting future disaggregated architectures and distributed high-performance computing (HPC) systems," said Marco Chisari, EVP of Samsung Electronics and Head of the Samsung Semiconductor Innovation Center.

"We are excited to participate in this round at Avicena," said Amir Salek, Senior Managing Director at Cerberus Capital Management and former Head of silicon for Google Infrastructure and Cloud. "Avicena has a highly differentiated technology addressing one of the main challenges in modern computer architecture. The technology offered by Avicena meets the needs for scaling future HPC and cloud compute networks and covers applications in conventional datacenter and 5G cellular networking."

As The CHIPS and Science Act of 2022 heads to President Biden's desk for his signature, following its passage in Congress, OSTP's Dr. Alondra Nelson is releasing the following statement: "The bipartisan CHIPS and Science Act of 2022 is the most significant American investment in science, technology, and innovation in a generation. It will revitalize and advance U.S. leadership in science and technology, spur U.S. competitiveness and economic development, and bolster our domestic semiconductor supply chains. Most important, it will deliver opportunities for Americans all across the nation.

For working Americans, the stakes of this legislation could not be higher. Semiconductor chips power our daily lives, from the telecommunications that keep us all connected, and medical devices that keep our loved ones alive, to financial institutions that help secure our families' futures, and the computers from which millions of Americans run their businesses. They are a door to a future of innovation, progress, and economic security.

Based on a report from IC Insights, it appears that the demand for semiconductors and memory is starting to slow down. The slowdown is industry wide, with most major players having seen a reduction in sales in June compared to May. Although the report is focused on Taiwanes semiconductor companies, it also mentions Micron, who is expecting a slowdown in the third quarter of this year. Micron is reportedly expecting a drop in sales by as much as 17 percent, although this past quarter the company saw an increase in sales by 11 percent compared to the previous quarter, or 19 percent compared to last year, so it could simply be that the market is starting to normalise.

As for the Taiwanese semiconductor companies, TSMC saw a reduction in sales of five percent in June, although its competitor UMC saw an increase of two percent. Two other Taiwanese foundries, Powerchip and Vanguard, saw a decrease of four percent and an increase of three percent respectively, which shows that the foundry businesses are seeing change based on the type of chips they make. Apart from Winbond and Macronix, the other four companies in the report saw a decrease in sales by anything between two and 26 percent. Novatek, a manufacturer of semiconductors for the display industry saw the biggest dip in sales, with memory manufacturer Nanya seeing a drop of 16 percent. It should be pointed out that Novatek saw an increase in sales of 78 percent during the pandemic, which suggests their customers might not be seeing the same demand for their end products as they did over the past two years. For now, this could just be a slowdown over the summer months, when demand is usually quite low, but it could also be an indication of a return to a more normalised market.

Samsung Foundry will engage Ansys' industry-leading electromagnetic (EM) simulation tools to develop ultramodern designs, including 5G/6G, on the most advanced chips, nodes, and process technologies. Ansys' simulation solutions will deliver a comprehensive EM-aware design flow with greater capacity, speed, and integration capabilities for Samsung's most advanced semiconductor technology, accelerating on-chip design cycle times to boost high-speed connectivity while helping to reduce design error and risk.

Samsung designers will leverage Ansys' EM design tools, Ansys RaptorX, Ansys VeloceRF, and Ansys Exalto, to help reduce time to market by two to three weeks on smaller designs and up to two months for complex designs. With automation capabilities that optimize calculations and modeling, coupled with larger capacity, Ansys' software will allow the Samsung team to design at faster speeds with higher fidelity.

Today, leading global fabless chipmaker MediaTek Inc., [joined by Indiana Governor Eric J. Holcomb, Deputy Secretary of Commerce Don Graves, Indiana Secretary of Commerce Bradley B. Chambers, and Purdue College of Engineering's Dr. Mung Chiang] announced their commitment to accept a state transition assistance package from the Indiana Economic Development Commission (IEDC) to support its very first Midwest semiconductor chip design center in West Lafayette, Indiana. MediaTek also shared its intention to create a new research partnership with Purdue to collaborate on engineering talent development and new research on next-generation computing and communications chip design. The news was shared with senior leaders, other international investors and policymakers assembled in National Harbor, Maryland for the 2022 SelectUSA Investment Summit.

This novel partnership in Indiana represents a new U.S. growth model for MediaTek USA; outside the traditional centers of gravity for chip design. "We believe strongly that being in Indiana means we'll have access to some of the best engineering talent in the world," said Dr. Kou-Hung Lawrence Loh, Corporate Senior Vice President of MediaTek Inc. and President of MediaTek USA, Inc. "Not just at Purdue, but West Lafayette is only four hours away from nearly a dozen of the top engineering schools in the country. In the post pandemic world, top candidates tell us they want to be closer to home, near family and they want to have a real house and great schools. Indiana offers all that and more."

Hsinchu, Taiwan-based global semiconductor silicon wafer company, GlobalWafers, announced today that it plans to build a state-of-the-art 300-millimeter silicon wafer factory in Sherman, Texas, which is the first of its kind in the USA over twenty (20) years. Construction is expected to commence later this year. This 300-millimeter greenfield investment is consistent with the Company's announcement on February 6th of this year of brownfield and greenfield expansions totaling NTD 100 bn. This new Texas investment could also support as many as 1,500 jobs with production volumes ultimately reaching 1.2 mn wafers per month after multiple stages of equipment installation, in alignment with market demand.

300-millimeter silicon wafers are the starting material for all advanced semiconductor fabrication sites (or fabs), including recently announced United States (US) expansions by GlobalFoundries, Intel, Samsung, Texas Instruments and TSMC. Most of these wafers are currently manufactured in Asia, forcing the US semiconductor industry to highly rely on imported silicon wafers. This investment will represent the first new silicon wafer facility in the US in over two decades and close a critical semiconductor supply chain gap.

According to TrendForce, market conditions in 1H22 were chaotic and there was disparate demand for chips of varying functionality. Given the global development of electronic devices and power systems, overall demand for power management ICs (PMIC) is still relatively good. PMICs are used in consumer electronics, communications, computing, industrial control, automotive and other fields. In 2H22, supply and demand gradually diverged and demand for automotive Switching Regulators, Multi Channel PMICs was strongest.

According to TrendForce, there are various specifications and types of PMICs, including Linear Regulators, etc. Even usage scenario dependent products such as Battery Charging & Management, Voltage References, and USB Power Delivery ICs all fall into this category.

Global fab equipment spending for front-end facilities is expected to increase 20% year-over-year (YOY) to an all-time high of US$109 billion in 2022, marking a third consecutive year of growth following a 42% surge in 2021, SEMI announced today in its latest quarterly World Fab Forecast report. Fab equipment investment in 2023 is expected to remain strong.

"The global semiconductor equipment industry remains on track to cross the $100 billion threshold for the first time as shown in our latest update of the World Fab Forecast,"said Ajit Manocha, president and CEO of SEMI. "This historic milestone puts an exclamation point on the current run of unprecedented industry growth."

According to the latest TrendForce statistics, the top ten IC designers worldwide posted a combined revenue of US$39.43 billion in 1Q22, or 44% growth YoY. Qualcomm, NVIDIA, Broadcom ranked in the top three. After the acquisition of Xilinx, AMD surpassed MediaTek in the fourth position. In addition, according to TrendForce tracking of IC design industry trends, revenue generated by Will Semiconductor and Cirrus Logic was enough to be included in the top ten for the first time.

Benefiting from growth performance in handsets and RF front-end divisions in addition to its IoT and automotive divisions in 1Q22, Qualcomm's quarterly revenue reached US$9.55 billion, or 52% growth YoY, ranking number one in the world. The expanded application of GPUs in data centers boosted this portion of NVIDIA's revenue to 45.4%, surpassing the 45% accounted for by its gaming business, combining for a total revenue of US$7.9 billion, or 53% growth YoY. Broadcom's revenue from semiconductor solutions is substantial, including network chips, broadband communication chips, and storage and bridging chips. Its business has maintained stable sales performance, with revenue reaching US$6.11 billion, or 26% growth YoY. After the addition of Xilinx, AMD's revenue reached US$5.89 billion, or 71% growth YoY. However, even excluding Xilinx, due to strong sales in its enterprise, embedded and semi-customized divisions, AMD's own business revenue still hit an all-time high of US$5.33 billion.

Foxconn's ambitions as a semiconductor player are growing with yet another potential joint venture being announced, this time in Malaysia. Hang on, Foxconn doesn't make semiconductors you might be thinking right now, but the company has actually owned semiconductor fabs since 2016, when it acquired Sharp and ended up with an 8-inch fab in Fukuyama in Japan. Foxconn has also tried to buy an 8-inch fab in Malaysia in 2020, as well as trying to take over Taiwanese non-volatile memory manufacturer Macronix at one point. It seems like the company has decided to take a different route this year, with news of a joint venture in India and now plans of another joint venture with Dagang NeXchange Berhad (DNex) in Malaysia.

The two companies have signed a memorandum of understanding (MOU), although it's a subsidiary of Foxconn, Big Innovation Holding Limited (BIH) that actually signed the paperwork. The MOU is about building a 12-inch fab according to Focus Taiwan/CNA which reports that the fab will be making chips using 40 to 28 nm processes. It's possible that this will be for the various EV projects that Foxconn is involved with and it would be a less risky way to enter the semiconductor market for Foxconn. The fab is said to be able to output 40,000 wafers a month once it starts, although when this will be is anyone's guess at the moment. Foxconn's focus is on what the company calls the 3 plus 3 initiative, which relates to electrical vehicles, robotics and healthcare solutions, which are built in AI, semiconductors and communication technologies, all presumably from within Foxconn. Time will tell if Foxconn manages to pull this off, but until the construction of the fab has started, this is nothing more than a potential project for Foxconn.

International semiconductor consortium or ISMC is a new joint venture between Abu Dhabi-based Next Orbit Ventures and Israeli Tower Semiconductor that is getting ready to invest big. The consortium is said to be looking at investing no less than US$3 billion in a chip foundry based in Karnataka, India. Maybe the most interesting part here is that Tower Semiconductor is set to be acquired by Intel, assuming the deal passes all regulatory reviews. This means that Intel could be replacing Tower Semiconductor in the consortium before the new fab has been finished.

Not much information is available about ISMC, but the planned chip plant would be one of the first foundries in India, as well as the largest foundry in the nation. So far ISMC has only signed a memorandum of Understanding with the government of Karnataka, so things could still change. However, the US$10 billion incentive by the central Indian government might be part of the reason behind the decision. Tower Semiconductor specialises in various speciality process technologies, such as SiGe, BiCMOS and SOI and manufacturer mixed-signal and RFCMOS chips, as well as CMOS based image sensors, power management chips and various types of non-volatile memory and some MEMS products for its customers. The new fab is expected to bring 1,500 direct and some 10,000 indirect jobs to the region.

Kyocera Corporation (hereinafter "Kyocera;" President: Hideo Tanimoto) today announced a plan to build the largest manufacturing facility it has ever operated in Japan, expanding production capacity for components including organic semiconductor packages and crystal device packages. A signing ceremony held April 20, 2022 was attended by Kagoshima Governor Koichi Shiota, Satsumasendai City Mayor Ryoji Tanaka, and Kyocera officials. Construction is scheduled to begin next month at the company's Sendai Plant Campus in Kagoshima.

Three converging factors are creating strong demand for Kyocera's organic semiconductor packages and crystal device packages. Smart vehicles are expanding the need for automotive cameras and high-performance processors used in Advanced Driver-Assistance Systems (ADAS) and autonomous driving. New communications infrastructures, including fifth-generation (5G) base stations and datacenters, are being deployed worldwide. In addition, the rising trend toward digitalization is expanding demand for electronic products ranging from personal computers and smartphones to consumer goods, industrial automation, and others. Kyocera will open the new facility in October 2023 to serve these growing trends, aiming for a 4.5-fold increase in production capacity for organic packages at the Sendai Plant Campus, as well as a substantial increase in capacity for crystal device packages. Kyocera will contribute to the community by stimulating economic development in Kagoshima, creating new employment opportunities through expanded production of semiconductor components in response to global demand.

Intel, Micron, Analog Devices, and MITRE Engenuity announced they have an agreement of principles to accelerate semiconductor research, development, and prototyping to build a more robust U.S. semiconductor industry, foster advanced manufacturing in the United States, and protect intellectual property amid increased global competition. This engagement signifies a commitment to collaborate on ensuring the resiliency of the industry. It establishes the Semiconductor Alliance to propose the foundation for a whole-of-nation approach for a more innovation-focused U.S. semiconductor industry and supply chain, one that ensures American innovation truly leads to American growth.

The Semiconductor Alliance, led by MITRE Engenuity, was developed from working groups in 2021, and its principles were published in a white paper on American Innovation for American Growth summarizing the Alliance's whole-of-nation call to action for a fair and objective National Semiconductor Technology Center (NSTC). The leading U.S. semiconductor manufacturers—Intel, Micron, and Analog Devices—and MITRE Engenuity seek engagement from industry and experts from all facets of the U.S. semiconductor ecosystem, including integrated device manufacturers; fabless chip companies; providers of infrastructure, design, and manufacturing tools; and technology innovators from industry and academia. MITRE Engenuity is built on MITRE's 60+ year history of serving as an independent, objective bridge and convener of government, industry, and academia, bringing together the whole of nation to tackle some of the biggest challenges to our national security.

ERS electronic, the industry leader in the market of thermal management solutions for semiconductor manufacturing, reveals the details of its third-generation flagship thermal debond machine, ADM330. The machine was introduced to the market in 2007 as the first-of-its-kind. Since then, it has become an industry-favourite and can be found on the production floors of most semiconductor manufacturers and OSATs involved in Advanced Packaging worldwide.
Earlier this month, the company was recognized for its continuous innovation and contribution to heterogeneous integration technologies with a 3D InCites "Equipment Supplier of the Year" award.

ERS is now giving a first look at the next-generation ADM330, which has changed its previously matte metallic appearance to a clean, white surface matching most equipment found in a cleanroom. In addition, the machine is now fully compliant with the GEM300 SEMI standards, thus allowing seamless integration into automated fabs and Industry 4.0 architectures. Warpage adjustment performance has also been improved thanks to a unique thermal chuck design that enables a strong vacuum performance three times better than its predecessor. Lastly, the new ADM330 offers an implemented add-on software feature allowing stand-alone laser marking for improved wafer traceability.

At 01:41 in the morning of the 23rd of March, the southeast coast of Taiwan experienced a magnitude 6.6 earthquake in the ocean outside Hualien County. The quake was felt island wide and some of the factories that operate 24/7 evacuated staff as a precautionary measure. All affected companies claim to have resumed operations later the same day, after checking that no damage was caused by the quake. The southeast of Taiwan kept being hit by minor quakes for the rest of the night and day, with some being felt across the island.

TSMC and UMC both claimed that the quake had a minimal effect on production, although production equipment had gone into self-protect mode, which was largely the reason for no production issues taking place. Powerchip Semiconductor on the other hand had a two to three hour production loss and Vanguard International Semiconductor was reported saying they were checking for defects in their production. AU Optronics and Innolux were also saved by their various safeguards against earthquake damage and both companies were expecting to return to normal production shortly. Other companies are said to have reported issues with their production equipment, but no damage to the actual products they produce.

There have been several announcements of new semiconductor fabs being built all over the world, but those fabs might end up being empty shells, all because of a single company. ASML or Advanced Semiconductor Materials Lithography if you prefer, is a Dutch company that produces various types of photolithography machines that are used to produce semiconductors. They're the world leader in their field and their machines are used by the likes of Intel and TSMC to do the physical etching of the silicon wafers that semiconductors are produced from. Now a warning from ASML's CEO, Peter Wennink has arrived, stating that the company can't keep up with demand.

The company isn't expecting to fulfil orders for at least the next couple of years, despite expecting to ship more machines this year than last year and more machines next year than this year. As each of these machines are largely custom made for its customers and hand built, due to the low production volumes, it takes a lot of time to construct each of these huge machines. Wennink said that the company "really needs to step up our capacity significantly more than 50 per cent. That will take time."

The output value of the world's top 10 foundries in 4Q21 reached US$29.55 billion, or 8.3% growth QoQ, according to TrendForce's research. This is due to the interaction of two major factors. One is limited growth in overall production capacity. At present, the shortage of certain components for TVs and laptops has eased but there are other peripheral materials derived from mature process such as PMIC, Wi-Fi, and MCU that are still in short supply, precipitating continued fully loaded foundry capacity. Second is rising average selling price (ASP). In the fourth quarter, more expensive wafers were produced in succession led by TSMC and foundries continued to adjust their product mix to increase ASP. In terms of changes in this quarter's top 10 ranking, Nexchip overtook incumbent DB Hitek to clinch 10th place.

TrendForce believes that the output value of the world's top ten foundries will maintain a growth trend in 1Q22 but appreciation in ASP will still be the primary driver of said growth. However, since there are fewer first quarter working days in the Greater China Area due to the Lunar New Year holiday and this is the time when some foundries schedule an annual maintenance period, 1Q22 growth rate will be down slightly compared to 4Q21.

At present, the materials with the most development potential are Wide Band Gap (WBG) semiconductors with high power and high frequency characteristics, including silicon carbide (SiC) and gallium nitride (GaN), which are mainly used in electric vehicles (EV) and the fast charging battery market. TrendForce research estimates, the output value of third generation power semiconductors will grow from US$980 million in 2021 to US$4.71 billion in 2025, with a CAGR of 48%.

SiC is suitable for high-power applications, such as energy storage, wind power, solar energy, EVs, new energy vehicles (NEV) and other industries that utilize highly demanding battery systems. Among these industries, EVs have attracted a great deal of attention from the market. However, most of the power semiconductors used in EVs currently on the market are Si base materials, such as Si IGBT and Si MOSFET. However, as EV battery power systems gradually develop to voltage levels greater than 800 V, compared with Si, SiC will produce better performance in high-voltage systems. SiC is expected to gradually replace part of the Si base design, greatly improve vehicle performance, and optimize vehicle architecture. The SiC power semiconductor market is estimated to reach US$3.39 billion by 2025.

The Canadian government is getting ready to invest C$240 million (about US$187 million) into what the country calls the Semiconductor Challenge Callout. C$90 million of that will go towards the Canadian Photonics Fabrication Centre (CPFC), which is as the name implies, a facility that engineers and manufactures a range of photonics products, mostly on the prototyping level. The remaining C$150 million is up for grabs through the Strategic Innovation Fund, which is a government fund set up to help Canadian companies grow.

François-Philippe Champagne, the Canadian Minister of Innovation, Science and Industry is quoted as saying "By investing in Canada's semiconductor industry, we are making a firm commitment to businesses looking to invest in Canada. Whether it's high-value or large-scale manufacturing, we want to see Canada be home to the world's leading semiconductor manufacturers.". Exactly which companies will be asking for a share of the money is currently up in the air, but according to The Register, the Canadian government is looking for a wide range of potential semiconductor related businesses. Some examples are 2.5D and 3D chip packaging, MEMS sensor manufacturing and so on. None of this is compared to what the US, EU, Taiwan, Korea and the PRC are currently working on, but it could very well end up being supplemental to much of what's going on in the US semiconductor market right now.

Intel, along with Advanced Semiconductor Engineering Inc. (ASE), AMD, Arm, Google Cloud, Meta, Microsoft Corp., Qualcomm Inc., Samsung and Taiwan Semiconductor Manufacturing Co., have announced the establishment of an industry consortium to promote an open die-to-die interconnect standard called Universal Chiplet Interconnect Express (UCIe). Building on its work on the open Advanced Interface Bus (AIB), Intel developed the UCIe standard and donated it to the group of founding members as an open specification that defines the interconnect between chiplets within a package, enabling an open chiplet ecosystem and ubiquitous interconnect at the package level.

"Integrating multiple chiplets in a package to deliver product innovation across market segments is the future of the semiconductor industry and a pillar of Intel's IDM 2.0 strategy," said Sandra Rivera, executive vice president and general manager of the Datacenter and Artificial Intelligence Group at Intel. "Critical to this future is an open chiplet ecosystem with key industry partners working together under the UCIe Consortium toward a common goal of transforming the way the industry delivers new products and continues to deliver on the promise of Moore's Law."

Much of the globalized world's logistics is still in disarray from the COVID-19 pandemic, and now, Russia has thrown its weight on the matter through its invasion of Ukraine. As the initial offensive played out in the early hours of February 24th, semiconductor industry analysts turned to the situation with a prying eye - how exactly could this deadlock, and the following political and economical sanctions towards Russia, impact the semiconductor industry? The consensus seems to be a favorable one: not that much.

"The semiconductor industry has a diverse set of suppliers of key materials and gases, so we do not believe there are immediate supply disruption risks related to Russia and Ukraine," said John Neuffer, chief executive and president of the Semiconductor Industry Association. That sentiment was echoed by Intel; a company representative told Bloomberg that the company does not anticipate "(...) any impact on our supply chain. Our strategy of having a diverse, global supply chain minimizes our risk of potential local interruptions."

Back in December, we reported that Tower Semiconductor was one of several semiconductor manufacturers that was considering building a fab in India, largely due to government subsidies. Since then, Intel has stepped in and bought Tower Semiconductor and has taken over the negotiations with the Indian government. What has also come to light is that Tower Semiconductor has been in discussions with the Indian government for over a decade, but apparently the two parties have been unable to come up with a suitable agreement. Tower Semiconductor was apparently ready to cancel any plans on building in India as late as September 2021, but the more recent government initiative renewed their interest.

As to exactly what kind of fab Intel would build, is unclear at this point in time, but it might still be a MEMS fab or it could simply be a testing and packaging plant. Regardless of what kind of facility it'll be, it's interesting that Intel decided to keep the ongoing plans from Tower Semiconductor going. Tower Semiconductor mostly manufactured for fabless companies and were producing some two million wafers a year. It's likely that Intel will carry on producing for the same companies at the same terms for now, although as Tower Semiconductor gets integrated closer with the Intel foundry, things could change.
