Sapphire NITRO+ RX 9070 XT

11348-01-20G

Graphics Processor

Navi 48

Cores

4096

TMUs

256

ROPs

128

Memory Size

16 GB

Memory Type

GDDR6

Bus Width

256 bit

I/O

Top

Bottom

This product is not released yet.

Data on this page may change in the future.

Graphics Processor

GPU Name: Navi 48

GPU Variant: Navi 48 XT

Architecture: RDNA 4.0

Foundry: TSMC

Process Type: N4C FinFET

Process Size: 5 nm

Transistors: 53,900 million

Density: 151.0M / mm²

Die Size: 357 mm²

Chip Package: Monolithic

Graphics Card

Release Date: Mar 6th, 2025

Announced: Jan 6th, 2025

Generation: Navi IV
(RX 9000)

Predecessor: Navi III

Production: Unreleased

Bus Interface: PCIe 5.0 x16

Clock Speeds

Base Clock: 1660 MHz

Game Clock: ~~2400 MHz~~
2520 MHz (+5%)

Boost Clock: ~~2970 MHz~~
3060 MHz (+3%)

Memory Clock: 2518 MHz
20.1 Gbps effective

Memory

Memory Size: 16 GB

Memory Type: GDDR6

Memory Bus: 256 bit

Bandwidth: 644.6 GB/s

Render Config

Shading Units: 4096

TMUs: 256

ROPs: 128

Compute Units: 64

Tensor Cores: 128

RT Cores: 64

L0 Cache: 32 KB per WGP

L1 Cache: 128 KB per Array

L2 Cache: 8 MB

L3 Cache: 64 MB

Theoretical Performance

Pixel Rate: ~~380.2 GPixel/s~~
391.7 GPixel/s

Texture Rate: ~~760.3 GTexel/s~~
783.4 GTexel/s

FP16 (half): ~~97.32 TFLOPS~~
100.3 TFLOPS (2:1)

FP32 (float): ~~48.66 TFLOPS~~
50.14 TFLOPS

FP64 (double): ~~1.521 TFLOPS~~
1.567 TFLOPS (1:32)

Board Design

Slot Width: ~~Dual-slot~~
Triple-slot

Length: 331 mm
13 inches

Width: 129 mm
5.1 inches

Height: 66 mm
2.6 inches

TDP: ~~304 W~~
330 W

Suggested PSU: 700 W

Outputs: 1x HDMI 2.1b
3x DisplayPort 2.1a
2x HDMI 2.1b
2x DisplayPort 2.1a

Power Connectors: 2x 8-pin

Graphics Features

DirectX: 12 Ultimate (12_2)

OpenGL: 4.6

OpenCL: 2.2

Vulkan: 1.3

Shader Model: 6.8

Navi 48 GPU Notes

Generation: Navi IV
Codename:
Ray Tracing Cores: 3rd Gen
Matrix Cores: 3rd Gen
Infinity Cache: 3rd Gen
Graphics/Compute: 12.0.1
Shader ISA: GFX12.0 (gfx1201)
Display Core Next: 3.2.0
Video Core Next: 4.0.0
System DMA: 6.0.0

Other retail boards based on this design (29)

Name	GPU Clock	Boost Clock	Memory Clock	Other Changes
ASRock RX 9070 XT Steel Legend	1660 MHz	2970 MHz	2518 MHz	298 mm/11.7 inches, Triple-slot
ASRock RX 9070 XT Steel Legend Dark	1660 MHz	2970 MHz	2518 MHz	298 mm/11.7 inches, Triple-slot
ASRock RX 9070 XT Taichi OC	1870 MHz	3100 MHz	2518 MHz	330 mm/13 inches, Triple-slot
ASUS PRIME RX 9070 XT OC	1660 MHz	3060 MHz	2518 MHz	312 mm/12.3 inches
ASUS TUF Gaming RX 9070 XT OC	1660 MHz	3060 MHz	2518 MHz	330 mm/13 inches, Triple-slot
GIGABYTE AORUS RTX 9070 XT ELITE	1660 MHz	2970 MHz	2518 MHz	339 mm/13.3 inches, Triple-slot, 2x HDMI 2x DisplayPort
GIGABYTE RTX 9070 XT GAMING OC	1660 MHz	2970 MHz	2518 MHz	288 mm/11.3 inches, Triple-slot, 2x HDMI 2x DisplayPort
PowerColor Hellhound RX 9070 XT	1660 MHz	3010 MHz	2518 MHz	327 mm/12.9 inches
PowerColor Hellhound Special White RX 9070 XT	1660 MHz	3010 MHz	2518 MHz	327 mm/12.9 inches
PowerColor Reaper RX 9070 XT	1660 MHz	2970 MHz	2518 MHz	289 mm/11.4 inches
PowerColor Red Devil RX 9070 XT	1660 MHz	3060 MHz	2518 MHz	340 mm/13.4 inches, Triple-slot
PowerColor Red Devil RX 9070 XT Limited Edition	1660 MHz	3060 MHz	2518 MHz	340 mm/13.4 inches, Triple-slot
Sapphire NITRO+ RX 9070 XT	1660 MHz	3060 MHz	2518 MHz	331 mm/13 inches, Triple-slot, 2x HDMI 2x DisplayPort, 330 W
Sapphire PULSE RX 9070 XT	1660 MHz	2970 MHz	2518 MHz	320 mm/12.6 inches, Triple-slot
Sapphire PURE RX 9070 XT	1660 MHz	3010 MHz	2518 MHz	320 mm/12.6 inches, Triple-slot, 317 W
VASTARMOR RX 9070 XT Super Alloy	1870 MHz	3100 MHz	2518 MHz	327 mm/12.9 inches, Triple-slot
VASTARMOR RX 9070 XT Super Alloy White	1870 MHz	3100 MHz	2518 MHz	327 mm/12.9 inches, Triple-slot
XFX Mercury RX 9070 XT Gaming Edition	1660 MHz	2970 MHz	2518 MHz	360 mm/14.2 inches, Triple-slot
XFX Mercury RX 9070 XT OC Gaming Edition	1870 MHz	3100 MHz	2518 MHz	360 mm/14.2 inches, Triple-slot
XFX Mercury RX 9070 XT OC Magnetic Air Edition	1870 MHz	3100 MHz	2518 MHz	360 mm/14.2 inches, Triple-slot
XFX Mercury RX 9070 XT OC White Gaming Edition	1870 MHz	3100 MHz	2518 MHz	360 mm/14.2 inches, Triple-slot
XFX Mercury RX 9070 XT OC White Magnetic Air Edition	1870 MHz	3100 MHz	2518 MHz	360 mm/14.2 inches, Triple-slot
XFX Quicksilver RX 9070 XT Gaming Edition	1660 MHz	2970 MHz	2518 MHz	350 mm/13.8 inches, Triple-slot
XFX Quicksilver RX 9070 XT Magnetic Air Edition	1660 MHz	2970 MHz	2518 MHz	350 mm/13.8 inches, Triple-slot
XFX Quicksilver RX 9070 XT White Gaming Edition	1660 MHz	2970 MHz	2518 MHz	350 mm/13.8 inches, Triple-slot
XFX Quicksilver RX 9070 XT White Magnetic Air Edition	1660 MHz	2970 MHz	2518 MHz	350 mm/13.8 inches, Triple-slot
XFX Swift RX 9070 XT Triple Fan Edition	1660 MHz	2970 MHz	2518 MHz	325 mm/12.8 inches, Triple-slot
XFX Swift RX 9070 XT White Triple Fan Edition	1660 MHz	2970 MHz	2518 MHz	325 mm/12.8 inches, Triple-slot
Yeston RX 9070 XT Sakura Atlantis	1660 MHz	2970 MHz	2518 MHz
