Here are some of the first pictures of the Z97 WS from ASUS, its first workstation motherboard based on Intel's new 9-series chipset. Built in the standard ATX form-factor, the board offers a boat-load of enterprise-relevant connectivity, and out of the box support for not just Core "Haswell" Refresh processors, but also Xeon processors based on the "Haswell" silicon. The board draws power from 24-pin ATX and two 8-pin EPS connectors, with an optional 6-pin PCIe power input to stabilize power supply to add-on cards. It features an 8-phase CPU VRM, with additional heatsinks to dissipate heat from the MOSFETs.
The LGA1150 socket is wired to four DDR3 DIMM slots, and a PLX PEX8747 PCI-Express gen 3.0 x48 bridge chip. This chip wires out four PCI-Express 3.0 x16 slots, which auto-configure between x16/NC/x16/NC, x16/NC/x8/x8, and x8/x8/x8/x8, depending on how you populate the four slots. Other expansion slots include two PCIe 2.0 x1, and one PCIe 2.0 x4, wired to the PCH. Storage connectivity includes eight SATA 6 Gb/s, from which four convert to two SATA-Express ports, and one M.2 slot. Display outputs appear to include DisplayPort and HDMI. There are two gigabit Ethernet interfaces on offer, both driven by Intel-made controllers. 8-channel HD audio, several USB 3.0 ports, and legacy ports by headers, make for the rest of the connectivity. Its feature-set include Ai-Suite III, reinforced power connectors, and the ability to log system events onto USB flash drives.
